Webinar Schedule

Our webinars strengthen your knowledge of motion control design, servo sizing principles, application specific requirements and more industry insights that help you identify the optimal solutions for machine design and performance.

Check this page often to see new and upcoming events, and also to take advantage of our previously recorded webinars below.

Commercial Training Sessions

Technical Training Sessions

cymex® Sizing Webinars

July 29, 2021 10:30 CST

cymex® 5 Webinar: July 29 – Sizing for a Hygienic Servo System

More Details



August 26, 2021 10:30 CST

cymex® 5 Webinar: August 26 – Reduce your Footprint with WITTENSTEIN Servo Actuators

More Details



September 23, 2021 10:30 CST

cymex® 5 Webinar: September 23 – Sizing for a Delta Robot Application

More Details



October 28, 2021 10:30 CST

cymex® 5 Webinar: October 28 – Sizing a Rotary Table with the NEW flange-output NPT Gearbox

More Details



November 11, 2021 10:30  CST

cymex® 5 Webinar: November 11 – Sizing the NEW XP HIGH TORQUE Gearbox

More Details



December 16, 2021 10:30 CST

cymex® 5 Webinar: December 16 – Sizing a premo Actuator for Compact Precision and Power Density

More Details



January 27, 2022 10:30 CST

cymex® 5 Webinar: January 27 – Sizing the right Rack & Pinion Linear System

More Details



February 24, 2022 10:30 CST

cymex® 5 Webinar: February 24 – WITTENSTEIN Value Line is the Complete Package

More Details



March 31, 2022 10:30 CST

cymex® 5 Webinar: March 31 – Sizing a V-Drive in a Lumber Application

More Details


Recorded webinars


cymex® 5: Downsizing Your Servo System with alpha Premium

Adding a low-backlash planetary gearbox to a servo system generates more torque than a servo motor alone.  This allows for better inertia matching, greater system stiffness,  and reduces the overall size of the system's envelope.  WITTENSTEIN alpha Premium Line low-backlash gearboxes allow you to downsize further with less than 1 arc min backlash and greater torque values in a more compact frame.  In today's webinar, our Engineering Team will show you:

  • Performance characteristics of the alpha Premium Line
  • How to size a gearbox suitable for a high-performance system
  • How the alpha Premium Line delivers greater system flexibility

Register now



cymex® 5: Couplings and Quick Sizing

You may already know that cymex® 5 is a powerful tool to size and simulate your motor and gearboxes, but did you know that you can size your couplings as well? cymex® 5 includes a database of elastomer, bellows, and torque limiter couplings to complete your application. In today's webinar, join our North American Engineering Team Lead to learn this powerful tool. By the end, you will know:

  • How to utilize cymex® 5's database of couplings
  • How to identify and size the proper coupling for your application
  • How to Quick Size for your application

Register now



cymex® 5: Using Motor Trace Data

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing for a High-Speed Conveyor

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Advanced Calculations for Winders

cymex® 5 performs extensive background calculations when sizing your application.  For instance, cymex® 5 will track process forces, such as web tension, as well as dynamic variables that change throughout the motion profile for a winder, like the roll's inertia

Please register with your corporate email address.

Register now



cymex® 5: Sizing for a Slew Ring

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing a Ball Screw

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing a Linear System

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing a Master/Slave Rack & Pinon

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing a Worm Gear for a Winder

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Sizing for a Pinch Roller

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



cymex® 5: Using the Inertia Calculator

Our free sizing software cymex® 5 enables the simple dimensioning and evaluation of the complete drive train (application + transformation + motor + gearbox). The precise calculations are facilitated by predefined standard applications such as belt, spindle, rotary-table and rack & pinion drives. Consideration of all major influencing factors and customer-specific parameters result in a reliable and efficient design as well as optimization of the drive system.

Register now



Technical Training Session: Technical Training Session: Designed for Harsh Environments – the NPL-W

WITTENSTEIN enables corrosion resistance at an economic price. The NPL-W delivers mid-range power, precision, IP65 protection, and it's produced in WITTENSTEIN North America's Headquarters. In today's webinar, we'll showcase our new design and the technology behind it. By the end, you'll be able to identify applications to utilize the NPL-W's unique features.

Register now



Technical Training Session: Galaxie® Principles – the Zero Backlash Drive System

Galaxie® by WITTENSTEIN is a true zero-backlash drive system and gearbox. Its unique kinematics allow full surface during power transmission. Its compact frame and hollow shaft achieve the highest torque density, torsional rigidity, positioning accuracy and completely backlash free operation. Join WITTENSTEIN North America's Engineering team to learn the new ways that the Galaxie® Drive System "makes the impossible, possible" with its expanded portfolio.

Register now



Technical Training Session: The All-New XP+ HIGH TORQUE Gearbox

Meet the All-New XP+ HIGH TORQUE Gearbox from WITTENSTEIN. Your applications will achieve new levels of performance and controllability. Greater torque density allows you to downsize your system. Increased performance reduces your cycle times for steeper acceleration ramps, improved smooth running and positional accuracy. Join our international engineering experts to learn how the All-New XP+ HIGH TORQUE:

  • Delivers best-in-class torsional rigidity and torque capacity
  • Excels in highly dynamic application
  • Runs smoother with greater positional accuracy for increased machine performance

Register now



Technical Training Session: cyber® motor – New Small Servo Drive Systems

Meet  the newly designed cyber® simco® drive 2 controllers: They are up to 30% more compact than their predecessor and offer maximum connectivity with their multiple ethernet interface. They also feature real-time CIP sync functionality, decentralized intelligence and STO safety function. The new drives have also made it possible to realize the compact drive system cyber® dynamic system.

Register now



Technical Training Session: cyber® motor – Servo System Solutions for AGVs

Automated Guided Vehicles can perform a myriad of tasks and operate in a multitude of environments.  In today's webinar, we'll discuss key factors that help optimize the system and how WITTENSTEIN can size a servo drive to fit your needs.

Register now



Technical Training Session: cynapse – The Smart Gearbox

cynapse is changing everything. Thanks to an integrated sensor module, your gearbox is smart. Information such as vibration, temperature, acceleration, and operating hours is generated continuously to communicate with your machine infrastructure and all standard IIoT platforms. Join Digitalization Expert, Jakob Ackermann, to learn how cynapse:

  • Easily integrates into existing drive solutions
  • Collects and stores data throughout the gearbox's life cycle
  • Optimizes machine availability and prevents downtime

We ask that you please register under your corporate email address.

Register now



Technical Training Session: From Prototype to Optimal Production Design

In this webinar we’re going to present you how the Engineering Support from WITTENSTEIN can assist you along your journey from the first idea of a mechanical design, to a successful prototype testing and finally to an optimized servo system that is ready for production.

You’ll learn how WITTENSTEIN and cymex 5 can:

  • Help you minimize the risk of a failing prototype test
  • Evaluate the actual utilization of a servo system and further optimize

Register now



Technical Training Session: Motion Control Components – Enhance Machine Performance with alpha Premium Line

The requirements for highly complex applications used in machine tools or laser technology, for example, are becoming increasingly demanding and standard products are often unable to meet them. The alpha Premium Line is a completely new product program developed to meet the most demanding requirements.  In today's webinar, you'll learn how the alpha Premium Line can benefit your application:

  • If you require an even more compact system.
  • If you need to enhance your machine's performance.
  • If you require a high-performance linear system.

Register now



Technical Training Session: Motion Control Components – Hygienic Design and Corrosion Resistance

Corrosion protection is vitally important for quality and maintenance optimized production – to meet the rising worldwide demand for industrial cleaning technology. Our Corrosion Resistant and Hygienic Design products allow hygienic and sterile automation close to the process.  Join Regional Applications Manager, Evan Long, to learn how WITTENSTEIN can deliver crucial motion control components to Pharmaceutical and Food and Beverage production and packaging.  By the end, you will know:

  • What defines Hygienic Design
  • Hygienic Design and Corrosion Resistant applications and use cases
  • WITTENSTEIN's Hygienic Design and Corrosion Resistant Products

Register now



Technical Training Session: Motion Control Components – Machine Design Considerations

Servo systems are increasingly in demand by essential suppliers. Join John Ahart, Regional Sales and Applications Manager, to learn how a gearbox can increase a servo system's torque and efficiency while reducing the overall cost.

Register now



Technical Training Session: Motion Control Components – Models and Simulations to Confirm Assumptions

Many times, assumptions must be made when sizing an application when information is either insufficient or impossible to know.  In these instances, it is important to model and simulate scenarios in order to take appropriate actions.  Our free sizing software, cymex®5, allows you size and simulate entire drive trains. In this webinar, Phil Lucia will walk you through possible scenarios for a meat cutting application.

Register now



Technical Training Session: Motion Control Components – Sizing Considerations for a Turntable

Turntables are used in a variety of applications. They can be driven via a slew ring or mounted directly to the drive in different orientations.  Whether it's in a machine tool or a packaging line, rotary tables can be more or less accurate depending on their requirements.  In today's example, John Ahart will demonstrate step-by-step how a rotary table will be sized.

Register now



Commercial Training Session: WITTENSTEIN 101 – alpha Overview, Applications and More

WITTENSTEIN is renowned for our high-precision gearboxes, but did you know that we provide economy versions as well?  Join us as we explain the principles of gearboxes, introduce our portfolio of products, and walk through their applications on a  pharmaceutical packaging line. By the end, you will know:

  • How gearboxes can improve servo systems
  • WITTENSTEIN's full range of gearboxes
  • Where gearboxes can be used in a pharmaceutical application

Register now



Commercial Training Session: WITTENSTEIN 101 – Special Gearboxes, Linear Systems and More

WITTENSTEIN alpha offers planetary gearboxes, servo right-angle gearboxes, complete rack and pinion systems, design tools for the entire drive train and accessories. Our portfolio includes cost-effective serial solutions as well as customer-specific high-end developments. With our know-how, you achieve your goals. By the end, you will know:

  • Use cases for our Right Angle
  • Hygienic Design guidelines, principles and applications
  • Common Linear Systems and WITTENSTEIN solutions
  • Common linear system solutions

Register now



(Spanish) cymex® 5: Sizing a Linear System

Size and design your entire drive train (application + transformation + gearbox + motor) faster, easier and more reliably than ever before. Download our free sizing program, cymex® 5. In today's webinar, our Engineering team will look at sizing considerations for a drive train using a Rack & Pinion Linear System.

Register now



(Spanish) cymex® 5: Sizing a Ball Screw

Size and design your entire drive train (application + transformation + gearbox + motor) faster, easier and more reliably than ever before. Download our free sizing program, cymex® 5.  In today's webinar, our Engineering team will look at sizing considerations for a drive train using a Ball Screw.

Register now



(Spanish) cymex® 5: Sizing a Rotary Table

Size and design your entire drive train (application + transformation + gearbox + motor) faster, easier and more reliably than ever before. Download our free sizing program, cymex® 5.  In today's webinar, our Engineering team will look at sizing considerations for a drive train using a Rotary Table.

Register now
